| Screen size/category |
10-inch color touch screen |
| nozzle |
40um 50um 60um 70um |
| Flexible Tube |
long:2700mm diameter:21mm bending radius:150mm |
| Printing distance |
3mm-10mm(40um) 5mm-25mm(50um) 5mm~40mm(60/70um) |
| Print mode |
High speed, standard and high quality |
| Number of printing lines |
1 row (34 dots), 4 rows (7*5) |
| Printed fonts |
5x5，6x5，7x4，7x5，9x6，9x6 bold，11x8，11x8 bold，
16x11，24x17，32x22 |
| Print content |
Numbers, characters, QR codes, barcodes, shift schedules, patterns |
| Message Editing |
WYSIWYG |
| Interface Languages |
English |
| Data Interface |
USB,**TCP/IP,**RS232 |
| Electrical Requirements |
100-120V/200-240V AC 47-63Hz 3.5A Rated 156W (typical 92W) |
| Work environment |
5~45℃, 90% relative humidity, no condensation (using selected ink;
adjustments may be needed based on production environment; actual installation
may require additional hardware). |
| Protection Rating |
IP55 |
| Ink cartridge/solvent cartridge capacity |
750ml / 800ml |
| Applicable inks |
Dye type |
| Net weight |
25kg |
